USBLC6-2SC6Y

Identity

Manufacturer: ST(意法半导体)
Model / MPN: USBLC6-2SC6Y
LCSC: C2969755
Category: usb-esd-protection
Description: Automotive ultra-low-capacitance ESD protection, unidirectional, 2 channels, 12V clamp, 6V breakdown, 10nA Ir, 2.5pF, -40°C~+150°C.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

usb: interface

Package And Footprint

Package / footprint name: SOT-23-6L
Pin count: Unknown
EasyEDA symbol UUID: 3669f7d44e5442598743103361c8feb3
EasyEDA footprint UUID: 044d8cf8298647169a2aed60d4cddc4b
EasyEDA device UUID: fe7d9956358f4ddf879e2a27c31d5972
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common board support, timing, EMI, and protection seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/USBLC6-2SC6Y/3362219.html
Product URL: https://item.szlcsc.com/datasheet/USBLC6-2SC6Y/3362219.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category usb-esd-protection, interfaces usb, package SOT-23-6L, and EasyEDA footprint UUID 044d8cf8298647169a2aed60d4cddc4b.
