RP2040
Identity
- Manufacturer: Raspberry Pi(树莓派)
- Model / MPN: RP2040
- LCSC: C2961140
- Category: mcu
- Description: Microcontroller.
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- uart: interface
- spi: interface
- i2c: interface
- usb: interface
- adc: interface
Package And Footprint
- Package / footprint name: QFN-56-EP(7x7)
- Pin count: 56
- EasyEDA symbol UUID: 568f2fd43b76401b89017c30ceeb4118
- EasyEDA footprint UUID: 15757b50beef459687b43d4e3d79d366
- EasyEDA device UUID: a550c651585f4e7a9cc06e26cce54f4f
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common MCU and wireless module seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/RP2040/3349129.html
- Product URL: https://item.szlcsc.com/datasheet/RP2040/3349129.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: embedded control, firmware simulation, peripheral-rich custom boards
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
mcu, interfaces uart, spi, i2c, usb, adc, packageQFN-56-EP(7x7), and EasyEDA footprint UUID15757b50beef459687b43d4e3d79d366.
