SIM7080G

Identity

Manufacturer: SIMCOM(芯讯通无线科技)
Model / MPN: SIM7080G
LCSC: C2943992
Category: cellular-module
Description: Multiband CAT-M and NB-IoT module, SPI/USB/UART/I2C/PCM, B1/B2/B3, 2.7V~4.8V supply, PCM voice function.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

uart: interface
usb: interface
i2c: interface
spi: interface
sim: interface

Package And Footprint

Package / footprint name: SMD,17.6x15.7mm
Pin count: Unknown
EasyEDA symbol UUID: e36245d5763245a5b41d0b2ef471e0fa
EasyEDA footprint UUID: 9dc771b268c34cdda2f63c58440a0871
EasyEDA device UUID: 9456c30cdc544e7791b81e1f9717ddd0
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.7V~4.8V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/SIM7080G/3329189.html
Product URL: https://item.szlcsc.com/datasheet/SIM7080G/3329189.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category cellular-module, interfaces uart, usb, i2c, spi, sim, package SMD,17.6x15.7mm, and EasyEDA footprint UUID 9dc771b268c34cdda2f63c58440a0871.
