CD4053

Identity

Manufacturer: I-CORE(中微爱芯)
Model / MPN: CD4053
LCSC: C2943322
Category: analog-switch
Description: Triple 2-channel analog multiplexer/demultiplexer, -6V~~0V/3V~~9V, Switch Circuit:2:1, 3 channels, Ron:350Ω, 40MHz, tpd:10ns, -40°C~+85°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

analog: interface
gpio: interface

Package And Footprint

Package / footprint name: DIP-16
Pin count: Unknown
EasyEDA symbol UUID: b2604219f22c4d3f8ee93a4eaedcdeea
EasyEDA footprint UUID: 387429edf99c4b1691a005079f1d8f23
EasyEDA device UUID: e700fc7af33e44f288bc0f79b74fb287
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: Application-defined.
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common logic, level-shifting, bus-interface, and analog-switch seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/CD4053/3325981.html
Product URL: https://item.szlcsc.com/datasheet/CD4053/3325981.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: routing analog sensor paths, audio/control signals, low-resistance SPST/SPDT switching, and selectable measurement paths
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category analog-switch, interfaces analog, gpio, package DIP-16, and EasyEDA footprint UUID 387429edf99c4b1691a005079f1d8f23.
