LM74700QDBVRQ1

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: LM74700QDBVRQ1
• LCSC: C2941042
• Category: ideal-diode-controller
• Description: Low-IQ ideal diode controller for battery reverse-protection.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gate-drive: interface

Package And Footprint

• Package / footprint name: SOT-23-6
• Pin count: 6
• EasyEDA symbol UUID: 9b0409b61fad4860b3d38ef90caf1c5c
• EasyEDA footprint UUID: 136db59d42184a44ac8441e35d752b13
• EasyEDA device UUID: 6b6a7cc5a98644e1a1847d41bcf71e96
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified automotive reverse-battery protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/lm74700-q1
• Product URL: https://www.ti.com/cn/lit/gpn/lm74700-q1
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reverse-polarity protection, low-loss ORing, battery/adapter power-path selection, and backfeed blocking
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category ideal-diode-controller, interfaces gate-drive, package SOT-23-6, and EasyEDA footprint UUID 136db59d42184a44ac8441e35d752b13.

Search Keywords

seed:common-automotive-reverse-battery-protection, source:easyeda-bridge, automotive, common-pcb, power-protection, lm74700, reverse-battery-protection, low-iq, ti, ideal-diode-controller, sot-23-6, jlc-extended, gate-drive, jlc_extended, jlc-note:easyeda-jlc-verified-automotive-reverse-battery-protection-seed
