DC-023-1.65
Identity
- Manufacturer: HOOYA(皓宇电子)
- Model / MPN: DC-023-1.65
- LCSC: C2939110
- Category: dc-barrel-jack
- Description: DC power jack, Through Hole
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- Not captured yet.
Package And Footprint
- Package / footprint name: 插件
- Pin count: Unknown
- EasyEDA symbol UUID: ccba073ffb064c44ae14817a7d99152b
- EasyEDA footprint UUID: 796a6c0934ca42c6b54bcc2ec4b22bc4
- EasyEDA device UUID: 40709ed66a944a52bf6379a03ba29c11
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common board IO, power entry, and indicator expansion seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/DC-023-1.65/3300057.html
- Product URL: https://item.szlcsc.com/datasheet/DC-023-1.65/3300057.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
dc-barrel-jack, interfaces none captured, package插件, and EasyEDA footprint UUID796a6c0934ca42c6b54bcc2ec4b22bc4.
