WUSB3801Q-12/TR

Identity

Manufacturer: WILLSEMI(韦尔)
Model / MPN: WUSB3801Q-12/TR
LCSC: C2931342
Category: usb-c-controller
Description: WUSB3801Q-12/TR USB Type-C configuration-channel reversible adapter; 2.7V~~5.5V; 2 channels; 45uA supply, 1uA Iq; -40°C~~+125°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

usb: interface

Package And Footprint

Package / footprint name: QFN1616-12L(1.6x1.6)
Pin count: 1616
EasyEDA symbol UUID: 342df56e416842e1b59136c07057e923
EasyEDA footprint UUID: 4b77cae38a3d4a7594f3eee2e78548fc
EasyEDA device UUID: dd5e855329d9480297d08008d313e30c
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 45uA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.7V~5.5V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/WUSB3801Q-12%252FTR/3271865.html
Product URL: https://item.szlcsc.com/datasheet/WUSB3801Q-12%252FTR/3271865.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category usb-c-controller, interfaces usb, package QFN1616-12L(1.6x1.6), and EasyEDA footprint UUID 4b77cae38a3d4a7594f3eee2e78548fc.
