DW01A

Identity

• Manufacturer: YONGYUTAI(永裕泰)
• Model / MPN: DW01A
• LCSC: C2927799
• Category: battery-protection
• Description: DW01A lithium battery protection IC; 1.5V8V; saturation 4.3V; end-off 2.4V; 1 lithium cell; -40°C+85°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOT-23-6
• Pin count: 6
• EasyEDA symbol UUID: 5455d1d7bf10492a996a00225f0b686c
• EasyEDA footprint UUID: 136db59d42184a44ac8441e35d752b13
• EasyEDA device UUID: 3cd5a179f52a4caab8c16f8a7a45a98a
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.5V~8V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/DW01A/3256812.html
• Product URL: https://item.szlcsc.com/datasheet/DW01A/3256812.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category battery-protection, interfaces none captured, package SOT-23-6, and EasyEDA footprint UUID 136db59d42184a44ac8441e35d752b13.
