1N5819HW

Identity

Manufacturer: TECH PUBLIC(台舟)
Model / MPN: 1N5819HW
LCSC: C2905649
Category: schottky-diode
Description: Schottky diode, 40V, 1A, 900mV@3A Vf, 1mA@40V Ir, 9A non-repetitive peak forward surge current.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

Not captured yet.

Package And Footprint

Package / footprint name: SOD-123
Pin count: Unknown
EasyEDA symbol UUID: c0cf635c0ca9439094221b9daa3bcbcb
EasyEDA footprint UUID: 746219bd0d2d4f9db5c13c25b1bb4afb
EasyEDA device UUID: cc58cd10e12c431da6c7fac3a77414fe
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Passive part; no quiescent current.
Sleep / standby current: Passive part; no quiescent current.
Supply rails: 40V
Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common board support, timing, EMI, and protection seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/1N5819HW/3175946.html
Product URL: https://item.szlcsc.com/datasheet/1N5819HW/3175946.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category schottky-diode, interfaces none captured, package SOD-123, and EasyEDA footprint UUID 746219bd0d2d4f9db5c13c25b1bb4afb.

Search Keywords

seed:common-board-support-protection, source:easyeda-bridge, iot, common-pcb, 1n5819hw, 1a, 40v, sod-123, small-power, schottky-diode, jlc-extended, jlc_extended, jlc-note:easyeda-jlc-verified-common-board-support-timing-emi-and-protection-seed
