SIM7070G
Identity
- Manufacturer: SIMCOM(芯讯通无线科技)
- Model / MPN: SIM7070G
- LCSC: C2892847
- Category: cellular-module
- Description: LPWA module supporting Cat-M/Cat-NB/GPRS/EDGE, PCM/I2C/UART/SPI interfaces.
- Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- uart: interface
- i2c: interface
- spi: interface
- sim: interface
Package And Footprint
- Package / footprint name: LCC-68(24x24)
- Pin count: Unknown
- EasyEDA symbol UUID: 48c23f1dd3c6432aba815a15158c899e
- EasyEDA footprint UUID: de399a770a5949ff87809ad2c80c212a
- EasyEDA device UUID: 8107cb3be9e04d53aa7f2998ed352dc4
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Not characterized in seed; extract active current from datasheet tables.
- Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
- Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
- Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/SIM7070G/3126082.html
- Product URL: https://item.szlcsc.com/datasheet/SIM7070G/3126082.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
cellular-module, interfaces uart, i2c, spi, sim, packageLCC-68(24x24), and EasyEDA footprint UUIDde399a770a5949ff87809ad2c80c212a.
