BQ29700DSET

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: BQ29700DSET
• LCSC: C2876282
• Category: battery-protection
• Description: Voltage and current protection IC for single-cell Li-ion/Li-polymer battery, 300mV8V supply, 2.8V end-off, 1 cell, -40°C+85°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: WSON-6(1.5x1.5)
• Pin count: Unknown
• EasyEDA symbol UUID: 0f275b0dc8274074aa866490ddf0d291
• EasyEDA footprint UUID: 72281b3573494ddba1008a1bd25f6117
• EasyEDA device UUID: 417efa17222a4b4dac259d753e992487
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 300mV~8V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/bq2970
• Product URL: https://www.ti.com/cn/lit/gpn/bq2970
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category battery-protection, interfaces none captured, package WSON-6(1.5x1.5), and EasyEDA footprint UUID 72281b3573494ddba1008a1bd25f6117.
