TPS25940LRVCR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPS25940LRVCR
• LCSC: C2867756
• Category: efuse
• Description: 2.7V－18V eFuse with true reverse blocking and DevSleep support for SSD, 2.7V18V voltage rating, -40°C+125°C@(Tj).
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: WQFN-20-EP(3x4)
• Pin count: Unknown
• EasyEDA symbol UUID: dbb56fc1b4ef4138aedebbcc2846eeed
• EasyEDA footprint UUID: 462edcccd81e41118c59692b1dfad082
• EasyEDA device UUID: f98b5c0947df442685bcd6e76f19b5d5
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.7V~18V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power distribution, protection, and sensing seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tps25940
• Product URL: https://www.ti.com/cn/lit/gpn/tps25940
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: protected power inputs, hot-swap rails, surge-tolerant field power, configurable current limits, and fault reporting
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category efuse, interfaces gpio, package WQFN-20-EP(3x4), and EasyEDA footprint UUID 462edcccd81e41118c59692b1dfad082.
