SN65HVD230QD

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: SN65HVD230QD
• LCSC: C2864310
• Category: can-transceiver
• Description: SN65HVD230Q CAN transceiver, 3V3.6V supply, 1Mbps, 17mA, 1 channel, 600uA quiescent current, wake-up, -40°C+125°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• can: interface

Package And Footprint

• Package / footprint name: SOIC-8
• Pin count: 8
• EasyEDA symbol UUID: bdab8ea7224941c0be604ae4de4306b7
• EasyEDA footprint UUID: 1645372dca8547f19e87c6a19f78de2a
• EasyEDA device UUID: 3aeeafed47e54b4a86e07eb1ae0f24f0
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: EasyEDA property: 17mA.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 3V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power, analog, and interface IC seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/sn65hvd231q
• Product URL: https://www.ti.com/cn/lit/gpn/sn65hvd231q
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: vehicle and industrial CAN physical layer designs
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category can-transceiver, interfaces can, package SOIC-8, and EasyEDA footprint UUID 1645372dca8547f19e87c6a19f78de2a.
