INA181A1IDBVT

Identity

Manufacturer: TI(德州仪器)
Model / MPN: INA181A1IDBVT
LCSC: C2861997
Category: current-sense-amplifier
Description: INA181A1IDBVT Number of Channels:Single channel Supply Current:260uA Operating Temperature:-40℃~~+125℃ Operating Temperature:-40℃~~+125℃
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

analog: interface

Package And Footprint

Package / footprint name: SOT-23-6
Pin count: 6
EasyEDA symbol UUID: 04edb4373f174c71912c6213b380a169
EasyEDA footprint UUID: 136db59d42184a44ac8441e35d752b13
EasyEDA device UUID: 10c59b836ad9456db619a2e0d44c450a
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 260uA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common power distribution, protection, and sensing seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://www.ti.com/cn/lit/gpn/ina4181
Product URL: https://www.ti.com/cn/lit/gpn/ina4181
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: high-side or low-side shunt-current sensing, overcurrent detection, and analog current feedback
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category current-sense-amplifier, interfaces analog, package SOT-23-6, and EasyEDA footprint UUID 136db59d42184a44ac8441e35d752b13.
