TPS22919DCKT

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPS22919DCKT
• LCSC: C2860814
• Category: load-switch
• Description: 5.5V, 1.5A, 90mΩ self-protected load switch with controlled rise time, 1.6V5.5V, active high, 89mΩ, -40°C+105°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SC-70-6
• Pin count: 6
• EasyEDA symbol UUID: 4cfecbc4be474d94ae1bf3e5cc83574f
• EasyEDA footprint UUID: 825e604db13648a48ac2bccb4482f704
• EasyEDA device UUID: 932b574648aa4fbe948d20e9760f8016
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: Application-defined.
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tps22919
• Product URL: https://www.ti.com/cn/lit/gpn/tps22919
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category load-switch, interfaces gpio, package SC-70-6, and EasyEDA footprint UUID 825e604db13648a48ac2bccb4482f704.
