TSA002A3518B

Identity

• Manufacturer: BZCN(博众电气)
• Model / MPN: TSA002A3518B
• LCSC: C2846757
• Category: slide-switch
• Description: 243.5H-J 180gf slide switch, 12V, rectangular button, Surface Mount, Right Angle, 4.8mm x 2mm, height 3.5mm, 50mA
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SMD,4.8x2mm
• Pin count: Unknown
• EasyEDA symbol UUID: b4438e872c5f4fcdb2aac70f96cf6fd1
• EasyEDA footprint UUID: a1240eff9ebf4cb391ecca292a294742
• EasyEDA device UUID: 35a3b5ed783e4329a794e274081de786
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 12V
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connector, HMI, and mechanical interface seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/TSA002A3518B/3041760.html
• Product URL: https://item.szlcsc.com/datasheet/TSA002A3518B/3041760.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category slide-switch, interfaces gpio, package SMD,4.8x2mm, and EasyEDA footprint UUID a1240eff9ebf4cb391ecca292a294742.
