K2-1107ST-A4SW-06
Identity
- Manufacturer: 韩国韩荣
- Model / MPN: K2-1107ST-A4SW-06
- LCSC: C2837195
- Category: tactile-switch
- Description: K2-1107ST-A4SW-06 12V Operating Force:2.5N Mounting Type:Surface Mount,Vertical Length:6mm Width:3.6mm Switch Height:2.5mm Contact Current:50mA Voltage Rating:12V Life:100,000 Cycles Operating Temperature:-25℃
+85℃ Operating Temperature:-25℃+85℃ - Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- gpio: interface
Package And Footprint
- Package / footprint name: SMD,6x3.6mm
- Pin count: Unknown
- EasyEDA symbol UUID: a898ab1fbeac41879aa02ef26d780cec
- EasyEDA footprint UUID: bd2887e8bcf3405abac43110f9aa2583
- EasyEDA device UUID: 9d3ddf0af38441c4ba607069d982679c
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Passive part; no quiescent current.
- Sleep / standby current: Passive part; no quiescent current.
- Supply rails: 12V
- Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/K2-1107ST-A4SW-06/3006880.html
- Product URL: https://item.szlcsc.com/datasheet/K2-1107ST-A4SW-06/3006880.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
tactile-switch, interfaces gpio, packageSMD,6x3.6mm, and EasyEDA footprint UUIDbd2887e8bcf3405abac43110f9aa2583.
