BMI270

Identity

• Manufacturer: Bosch(博世)
• Model / MPN: BMI270
• LCSC: C2836813
• Category: imu
• Description: 6-axis IMU, 1.71V~3.6V, I2C/SPI, accelerometer X,Y,Z ±16g, gyroscope X,Y,Z ±2000dps
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface
• spi: interface

Package And Footprint

• Package / footprint name: LGA-14(2.5x3)
• Pin count: 14
• EasyEDA symbol UUID: 41d21458bb434af9a37b081fb997b7b2
• EasyEDA footprint UUID: 8965dcdfa934458d8a7278eb756a15b2
• EasyEDA device UUID: fedbf2107f05443eb14c04a2973b3dfb
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: EasyEDA property: 3.5uA.
• Supply rails: EasyEDA property: 1.71V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common environment, motion, light, proximity, and temperature sensor seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/BMI270/3005172.html
• Product URL: https://item.szlcsc.com/datasheet/BMI270/3005172.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: six-axis motion tracking, vibration, orientation, gesture inputs, dead-reckoning support, and motion-triggered wake
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category imu, interfaces i2c, spi, package LGA-14(2.5x3), and EasyEDA footprint UUID 8965dcdfa934458d8a7278eb756a15b2.
