BM8563ESA

Identity

Manufacturer: GATEMODE(捷茂微)
Model / MPN: BM8563ESA
LCSC: C269877
Category: rtc
Description: I2C real-time clock/calendar, 1.2V~~5.5V, 500nA supply, external crystal, alarm output, -40°C~~+85°C, Iq:0.5uA
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

i2c: interface

Package And Footprint

Package / footprint name: SOP-8
Pin count: 8
EasyEDA symbol UUID: da58e03d7d1c4af596a812b71810b1f5
EasyEDA footprint UUID: 2d2c4b680c114d399fbd60672a881771
EasyEDA device UUID: 4e72d254feaf4a6cb9c2709f7c235f29
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 500nA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 1.2V~5.5V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common memory, timing, storage, and security seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/BM8563ESA/259221.html
Product URL: https://item.szlcsc.com/datasheet/BM8563ESA/259221.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: battery-backed timekeeping, scheduled wakeups, timestamped logs, and low-power systems that need wall-clock time
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category rtc, interfaces i2c, package SOP-8, and EasyEDA footprint UUID 2d2c4b680c114d399fbd60672a881771.

Search Keywords

seed:common-memory-timing-security, source:easyeda-bridge, iot, common-pcb, storage, timing, security, bm8563, real-time-clock, i2c, low-power, sop-8, rtc, jlc-extended, jlc_extended, jlc-note:easyeda-jlc-verified-common-memory-timing-storage-and-security-seed, power
