ISO1211DR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: ISO1211DR
• LCSC: C2674102
• Category: isolated-digital-input
• Description: Isolated 24V to 60V digital input receiver for digital input modules, 1 input channel, IO output, 4Mbps, 2500Vrms isolation, 70kV/us CMTI.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOIC-8
• Pin count: 8
• EasyEDA symbol UUID: e04d4ea0d0f143168bc6bd49da54ad78
• EasyEDA footprint UUID: 1645372dca8547f19e87c6a19f78de2a
• EasyEDA device UUID: ec33c43f16ef4fcf84d4865a5d7d53f1
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified PLC-style industrial digital I/O seed (24V sinking/sourcing field I/O)
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/iso1211
• Product URL: https://www.ti.com/cn/lit/gpn/iso1211
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category isolated-digital-input, interfaces none captured, package SOIC-8, and EasyEDA footprint UUID 1645372dca8547f19e87c6a19f78de2a.
