TUSB320RWBR

Identity

Manufacturer: TI(德州仪器)
Model / MPN: TUSB320RWBR
LCSC: C2674065
Category: usb-c-controller
Description: TUSB320 USB Type-C configuration-channel logic and port controller; I2C; 400Kbps; 2.7V~~5V; 100uA Iq; 0°C~~+70°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

usb: interface

Package And Footprint

Package / footprint name: X2-QFN-12(1.6x1.6)
Pin count: 12
EasyEDA symbol UUID: f59620a3110d465b958fbb636c7f1eed
EasyEDA footprint UUID: f56db8cf9c5b476e998a6e479325d051
EasyEDA device UUID: 9a0398e2900e4c74aaf8c5140ce6ea76
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 100uA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.7V~5V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tusb320
Product URL: https://www.ti.com/cn/lit/gpn/tusb320
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category usb-c-controller, interfaces usb, package X2-QFN-12(1.6x1.6), and EasyEDA footprint UUID f56db8cf9c5b476e998a6e479325d051.
