SN74LVC4245AIPWREP

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: SN74LVC4245AIPWREP
• LCSC: C2652962
• Category: bus-transceiver
• Description: 8-bit bidirectional level shifter, VCCA 4.5V5.5V, VCCB 2.7V3.6V, 1 circuit, 8 channels.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: TSSOP-24
• Pin count: 24
• EasyEDA symbol UUID: 680212119fa0440682caac88ba2aa2fc
• EasyEDA footprint UUID: 7762658b53da4853bb54821c864851da
• EasyEDA device UUID: ded29230cb2a4faea365919abe8896b7
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified second batch of second-source/alternate seed for IC categories that only had one option
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/sn74lvc4245a-ep
• Product URL: https://www.ti.com/cn/lit/gpn/sn74lvc4245a-ep
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: parallel bus direction control, external memory or display interfaces, and isolating expansion headers
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category bus-transceiver, interfaces none captured, package TSSOP-24, and EasyEDA footprint UUID 7762658b53da4853bb54821c864851da.
