CAP1188-1-CP-TR

Identity

• Manufacturer: MICROCHIP(美国微芯)
• Model / MPN: CAP1188-1-CP-TR
• LCSC: C2652057
• Category: capacitive-touch-controller
• Description: CAP1188 1 CP TR 3V3.6V Number of Channels:8 Chip Function:Capacitive Touch Voltage - Supply:3V3.6V Voltage - Supply:3V3.6V Current - Supply:600uA Operating Temperature:-40℃+125℃ Operating Temperature:-40℃~+125℃ Standby Current:50uA ESD Protection Voltage:8kV
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface
• gpio: interface

Package And Footprint

• Package / footprint name: QFN-24-EP(4x4)
• Pin count: 24
• EasyEDA symbol UUID: 8c00f1cc00534e9d90c683d013fec904
• EasyEDA footprint UUID: 21e557e9ce874dc3bf95b5c47e372622
• EasyEDA device UUID: 9dd16358bd93401dbd1677aebed60c1a
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: EasyEDA property: 600uA.
• Sleep / standby current: EasyEDA property: 50uA.
• Supply rails: EasyEDA property: 3V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common HMI, display, audio, touch, and haptic seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/CAP1188-1-CP-TR/2743966.html
• Product URL: https://item.szlcsc.com/datasheet/CAP1188-1-CP-TR/2743966.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: sealed HMI controls, touch buttons, touch panels, wake inputs, and low-profile user interfaces
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category capacitive-touch-controller, interfaces i2c, gpio, package QFN-24-EP(4x4), and EasyEDA footprint UUID 21e557e9ce874dc3bf95b5c47e372622.
