XTR111AIDGQR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: XTR111AIDGQR
• LCSC: C26350
• Category: current-loop-transmitter
• Description: Precision voltage-to-current converter/transmitter; 7V44V; 1 channel; V-IConverter; built-in 3V voltage reference; -55°C+125°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: MSOP-10-EP
• Pin count: Unknown
• EasyEDA symbol UUID: ce6de5f5659c48bd9e10b286c67e1fa9
• EasyEDA footprint UUID: 5c7b28ae2f484d86b18abebe2aa40a2c
• EasyEDA device UUID: 04f6eadba6c44ed3b6e8d403f916011e
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 7V~44V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified industrial/machine analog I/O signal-conditioning seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/xtr111
• Product URL: https://www.ti.com/cn/lit/gpn/xtr111
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category current-loop-transmitter, interfaces none captured, package MSOP-10-EP, and EasyEDA footprint UUID 5c7b28ae2f484d86b18abebe2aa40a2c.
