HUSB238A-BB001-QN16R

Identity

• Manufacturer: Hynetek(慧能泰)
• Model / MPN: HUSB238A-BB001-QN16R
• LCSC: C24833806
• Category: usb-pd-sink-controller
• Description: HUSB238A-BB001-QN16R Power Receiver Controller 3.15V29.4V Type:Power Receiver Controller Protocol:PD 3.1；QC 2.0；BC 1.2 Number of Channels:1C Output Power:- Output Voltage:5V；20V；15V；12V；28V；9V；48V Voltage - Supply:3.15V29.4V Voltage - Supply:3.15V29.4V Operating Temperature:-40℃+125℃ Operating Temperature:-40
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• usb: interface
• i2c: interface

Package And Footprint

• Package / footprint name: QFN-16L-EP(3x3)
• Pin count: Unknown
• EasyEDA symbol UUID: cb9da36298664ee39b20e99049246d94
• EasyEDA footprint UUID: 2bee576f508947b78b98b650622977c0
• EasyEDA device UUID: 1c4c1444a51f48f6b8a289f94df5444c
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 3.15V~29.4V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/HUSB238A-BB001-QN16R/26562539.html
• Product URL: https://item.szlcsc.com/datasheet/HUSB238A-BB001-QN16R/26562539.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category usb-pd-sink-controller, interfaces usb, i2c, package QFN-16L-EP(3x3), and EasyEDA footprint UUID 2bee576f508947b78b98b650622977c0.

Search Keywords

seed:common-battery-usb-power, source:easyeda-bridge, iot, common-pcb, battery-power, usb-c-power, husb238a, usb-pd, sink, i2c, type-c, usb-pd-sink-controller, qfn-16l-ep-3x3, jlc-extended, usb, jlc_extended, jlc-note:easyeda-jlc-verified-common-battery-management-usb-c-power-and-power-path-seed, power
