SF-1206HH3000R-2
Identity
- Manufacturer: BOURNS
- Model / MPN: SF-1206HH3000R-2
- LCSC: C22445177
- Category: smd-fuse
- Description: 30A 50V Surface Mount Fuse Type:Surface Mount Fuse Current Rating:30A Voltage Rating (DC):50V Operating Temperature:-55℃
+150℃ Operating Temperature:-55℃+150℃ Melting I2t:280.2 Interrupt Rating:200A@50V Length:1.9mm Width:1.65mm Height:1mm - Source: EasyEDA/JLC verified common component seed
- Project designators: Not project-specific
- Project quantity per board: Not project-specific
Capabilities
- Not captured yet.
Package And Footprint
- Package / footprint name: 1206
- Pin count: Unknown
- EasyEDA symbol UUID: 27859cba7cf4476f9ebc5f5258fb7161
- EasyEDA footprint UUID: 4a6715cefd754571832848704353a1c1
- EasyEDA device UUID: 16da6ec3694946afae2d33ccfe80bcc2
- EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87
Power And Operating Modes
- Active current: Passive part; no quiescent current.
- Sleep / standby current: Passive part; no quiescent current.
- Supply rails: Application-defined.
- Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.
Procurement Classification
- JLC class: Extended Part
- JLC note / assembly basis: EasyEDA/JLC verified common debug headers, FPC/mezzanine connectors, field wiring terminals, and fuse seed
- Assembly status: jlc_extended
- Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
- Live stock: intentionally not stored as durable selection data; refresh externally before ordering.
Datasheet And Links
- Datasheet / product URL: https://item.szlcsc.com/datasheet/SF-1206HH3000R-2/24094187.html
- Product URL: https://item.szlcsc.com/datasheet/SF-1206HH3000R-2/24094187.html
- Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
Selection Notes
- Good for: non-resettable input protection, branch-rail protection, USB/load protection, and compact replace-by-rework fuse points
- Avoid when: Not captured yet.
- Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
- Equivalent search hints: match category
smd-fuse, interfaces none captured, package1206, and EasyEDA footprint UUID4a6715cefd754571832848704353a1c1.
