XC61CC2502MR-G

Identity

• Manufacturer: TOREX(特瑞仕)
• Model / MPN: XC61CC2502MR-G
• LCSC: C216610
• Category: voltage-monitor
• Description: XC61CC2502MR-G 700mV10V ChipType:Voltage Detector Output Type:Push-pull Voltage - Supply:700mV10V Voltage - Supply:700mV10V Reset Active Level:- Threshold Voltage:2.5V Number of Voltages Monitored:1 Reset Timeout:30us Operating Temperature:-40℃+85℃ Operating Temperature:-40℃~
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SOT-23
• Pin count: Unknown
• EasyEDA symbol UUID: 54a712877f4943c3906897086bdcb472
• EasyEDA footprint UUID: 400c969e1cc94bd38770939828bdc8f4
• EasyEDA device UUID: ce593a76c16745fc8e2b6c3a22532045
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 700mV~10V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power distribution, protection, and sensing seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/XC61CC2502MR-G/217560.html
• Product URL: https://item.szlcsc.com/datasheet/XC61CC2502MR-G/217560.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: overvoltage, undervoltage, window monitoring, reset generation, rail-good gating, and low-power wake or fault signals
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category voltage-monitor, interfaces gpio, package SOT-23, and EasyEDA footprint UUID 400c969e1cc94bd38770939828bdc8f4.
