TPS259535DSGR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPS259535DSGR
• LCSC: C2155672
• Category: efuse
• Description: TPS259535DSGR 2.7V18V Voltage Rating:2.7V18V Voltage Rating:2.7V18V Operating temperature:-40℃+125℃@(Tj) Operating temperature:-40℃~+125℃@(Tj)
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: WSON-8-EP(2x2)
• Pin count: Unknown
• EasyEDA symbol UUID: 4dfb1888531145dcad8c57744d681146
• EasyEDA footprint UUID: 8e5db56241be44d8b5bbf1a2c6c12b94
• EasyEDA device UUID: 5825800c44d146f1b044f01d9d715c8a
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.7V~18V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power distribution, protection, and sensing seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tps2595
• Product URL: https://www.ti.com/cn/lit/gpn/tps2595
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: protected power inputs, hot-swap rails, surge-tolerant field power, configurable current limits, and fault reporting
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category efuse, interfaces gpio, package WSON-8-EP(2x2), and EasyEDA footprint UUID 8e5db56241be44d8b5bbf1a2c6c12b94.
