SS8050(RANGE:200-350)

Identity

• Manufacturer: CJ(江苏长电/长晶)
• Model / MPN: SS8050(RANGE:200-350)
• LCSC: C2150
• Category: npn-transistor
• Description: NPN transistor, hFE=200~350, 1.5A, 25V, Pd:300mW, gain 200@800mA,1V, fT:100MHz, cutoff 100nA, VCE(sat):500mV
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOT-23
• Pin count: Unknown
• EasyEDA symbol UUID: 4a6e9a8a3e4a4f8d91920241ce2f0b2c
• EasyEDA footprint UUID: 18f92042a8ba46109ed61a02a6753de7
• EasyEDA device UUID: c9d39e24210c4c95bda0d293859cd880
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 25V
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: EasyEDA/JLC verified common passives and discretes seed
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/SS8050(RANGE%253A200-350)/2507.html
• Product URL: https://item.szlcsc.com/datasheet/SS8050(RANGE%253A200-350)/2507.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category npn-transistor, interfaces none captured, package SOT-23, and EasyEDA footprint UUID 18f92042a8ba46109ed61a02a6753de7.
