TPL7407LAPWR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPL7407LAPWR
• LCSC: C2149827
• Category: low-side-driver
• Description: 30V 7-channel low-side driver, 1.8V5V supply, active high control, reverse current blocking, -40°C+125°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: TSSOP-16
• Pin count: 16
• EasyEDA symbol UUID: 6cb86ad99ceb4134b38a9b3e1dcea41b
• EasyEDA footprint UUID: a11950ceac50438289ff689a35fd9574
• EasyEDA device UUID: 42a379829baa4cb6ad4bf782b40a8cde
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.8V~5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified second batch of second-source/alternate seed for IC categories that only had one option
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/ds/symlink/tpl7407la.pdf
• Product URL: https://www.ti.com/cn/lit/ds/symlink/tpl7407la.pdf
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category low-side-driver, interfaces none captured, package TSSOP-16, and EasyEDA footprint UUID a11950ceac50438289ff689a35fd9574.

Search Keywords

seed:common-single-option-category-expansion-2, source:easyeda-bridge, second-source, common-pcb, tpl7407l, low-side-switch, 7-channel, second-source-of:tbd62083, darlington-alternative, low-side-driver, tssop-16, jlc-extended, jlc_extended, jlc-note:easyeda-jlc-verified-second-batch-of-second-source-alternate-seed-for-ic-categories-that-only-had-one-option
