TPS22919DCKR

Identity

• Manufacturer: Texas Instruments
• Model / MPN: TPS22919DCKR
• LCSC: C2149796
• Category: load-switch
• Description: Load switch for modem
• Source: Fleet telematics BOM-VERIFIED.csv
• Project designators: U13, U14
• Project quantity per board: 2

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SC-70-6_L2.2-W1.3-P0.65-LS2.1-BR
• Pin count: 6
• EasyEDA symbol UUID: 5a4247e4a9a845c3a0b7a2646ad74bdb
• EasyEDA footprint UUID: c70deea011bd48e885ea06ea566c316d
• EasyEDA device UUID: 8a1ce68047294bee82c2cb647ddd4cbb
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed.
• Sleep / standby current: Not characterized in seed.
• Supply rails: Not characterized in seed.
• Notes: Capture rail limits, quiescent current, and enabled/disabled states when relevant.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: Standard
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/product/TPS22919
• Product URL: https://www.ti.com/product/TPS22919
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category load-switch, interfaces none captured, package SC-70-6_L2.2-W1.3-P0.65-LS2.1-BR, and EasyEDA footprint UUID c70deea011bd48e885ea06ea566c316d.

Search Keywords

seed:fleet-telematics, source:bom-verified, load-switch, jlc_extended, jlc-note:standard
