TLV62569DBVT

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TLV62569DBVT
• LCSC: C2071150
• Category: buck-converter
• Description: TLV62569DBVT Function:Step-down type Output Type:Adjustable Input Voltage:2.5V5.5V Input Voltage:2.5V5.5V Output Voltage:600mV5.5V Output Voltage:600mV5.5V Output Current:2A Switching Frequency:1.5MHz Switching Frequency:1.5MHz Operating Temperature:-40℃~+125℃@(TJ
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOT-23-5
• Pin count: 5
• EasyEDA symbol UUID: d3a78f64cac94efd838d1794563e7a17
• EasyEDA footprint UUID: dfda43b1e189428da33d965afe664484
• EasyEDA device UUID: 6d36da44c0664867abf5c947eaa3595a
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power, analog, and interface IC seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tlv62569
• Product URL: https://www.ti.com/cn/lit/gpn/tlv62569
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: power-tree designs when ratings and layout constraints fit
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category buck-converter, interfaces none captured, package SOT-23-5, and EasyEDA footprint UUID dfda43b1e189428da33d965afe664484.
