MMBT3904(RANGE:100-300)

Identity

• Manufacturer: CJ(江苏长电/长晶)
• Model / MPN: MMBT3904(RANGE:100-300)
• LCSC: C20526
• Category: npn-transistor
• Description: NPN transistor, hFE=100~300, 200mA, 40V, Pd:200mW, gain 100@10mA,1V, fT:300MHz, cutoff 100nA, VCE(sat):300mV
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SOT-23
• Pin count: Unknown
• EasyEDA symbol UUID: ea1495f934bc4375bd1beeef2a094eee
• EasyEDA footprint UUID: 18f92042a8ba46109ed61a02a6753de7
• EasyEDA device UUID: 79a17a80cabd40719b597fdc7a56f7bb
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/MMBT3904(RANGE%253A100-300)/21237.html
• Product URL: https://item.szlcsc.com/datasheet/MMBT3904(RANGE%253A100-300)/21237.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category npn-transistor, interfaces gpio, package SOT-23, and EasyEDA footprint UUID 18f92042a8ba46109ed61a02a6753de7.
