SX1262IMLTRT

Identity

• Manufacturer: SEMTECH
• Model / MPN: SX1262IMLTRT
• LCSC: C191341
• Category: lora-transceiver
• Description: SX1262IMLTRT 1.8V3.7V SPI Frequency Range:- Frequency Range:- Interface:SPI Voltage - Supply:1.8V3.7V Voltage - Supply:1.8V~3.7V Applications:General-purposeISM Output Power:22dBm Data Rate:300Kbps Current Of Transmitting:32mA Sensitivity:-148dBm Receive Current:4.2mA Operating T
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• spi: interface

Package And Footprint

• Package / footprint name: QFN-24-EP(4x4)
• Pin count: 24
• EasyEDA symbol UUID: e104e38444bd47238d1342c08e64c117
• EasyEDA footprint UUID: da24ee43f3db4089b1e00b9f88132dea
• EasyEDA device UUID: 4a36c81fc2904bdcb2694a734126f90d
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: EasyEDA property: 4.2mA.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.8V~3.7V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/SX1262IMLTRT/216566.html
• Product URL: https://item.szlcsc.com/datasheet/SX1262IMLTRT/216566.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category lora-transceiver, interfaces spi, package QFN-24-EP(4x4), and EasyEDA footprint UUID da24ee43f3db4089b1e00b9f88132dea.
