DRV8833CPWPR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: DRV8833CPWPR
• LCSC: C191171
• Category: motor-driver
• Description: Dual H-bridge motor driver, 2.7V~10.8V control and motor drive voltage, 700mA output, 2 H-bridges, bipolar driver.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface
• pwm: interface

Package And Footprint

• Package / footprint name: TSSOP-16-EP
• Pin count: 16
• EasyEDA symbol UUID: 98571516913a4bd394264ae153e172ca
• EasyEDA footprint UUID: 0636dcfecf9341618f8ab105f4a5c562
• EasyEDA device UUID: 944780571c85465e895eb7738b92c618
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/drv8833c
• Product URL: https://www.ti.com/cn/lit/gpn/drv8833c
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category motor-driver, interfaces gpio, pwm, package TSSOP-16-EP, and EasyEDA footprint UUID 0636dcfecf9341618f8ab105f4a5c562.

Search Keywords

seed:common-drivers-isolation-actuation, source:easyeda-bridge, iot, common-pcb, drv8833, dual-h-bridge, brushed-dc, stepper, low-voltage, motor-driver, tssop-16-ep, jlc-extended, gpio, pwm, jlc_extended, jlc-note:easyeda-jlc-verified-common-drivers-isolation-and-actuation-seed
