NS8002

Identity

• Manufacturer: Nsiway(纳芯威)
• Model / MPN: NS8002
• LCSC: C189960
• Category: audio-amplifier
• Description: 2.4W mono Class AB audio power amplifier, 3V~5.25V supply, 1-Channel, 1.8Wx1@4Ω, THD+N 0.1%, 6mA Iq, 85dB SNR, 80dB PSRR.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SOP-8
• Pin count: 8
• EasyEDA symbol UUID: 2b9f9ccbce1441aa9a8c2b5b4c7b528b
• EasyEDA footprint UUID: 114ea734da1646a1859a103ac7dff343
• EasyEDA device UUID: e329354430ec4b498778be3f8548e478
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 3V~5.25V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common HMI, display, audio, touch, and haptic seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/NS8002/207581.html
• Product URL: https://item.szlcsc.com/datasheet/NS8002/207581.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: audible alerts, speaker outputs, voice prompts, simple playback, and enclosure-mounted sound feedback
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category audio-amplifier, interfaces none captured, package SOP-8, and EasyEDA footprint UUID 114ea734da1646a1859a103ac7dff343.
