MCP2515T-I/ST

Identity

Manufacturer: MICROCHIP(美国微芯)
Model / MPN: MCP2515T-I/ST
LCSC: C185941
Category: can-controller
Description: Standalone CAN controller with SPI interface, 1Mbps data rate, 5mA supply, 2.7V~~5.5V supply, 1uA quiescent, -40°C~~+85°C.
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

spi: interface
can: interface

Package And Footprint

Package / footprint name: TSSOP-20
Pin count: 20
EasyEDA symbol UUID: 0418e8f7dfdd4635a44c4f5a6204bc1c
EasyEDA footprint UUID: 91fc5991e0a74a82ab525cc9f2487f9f
EasyEDA device UUID: 5e2056c6b70e4a11989a33a8e3f1a0c4
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: EasyEDA property: 5mA.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2.7V~5.5V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common power, analog, and interface IC seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/MCP2515T-I%252FST/197346.html
Product URL: https://item.szlcsc.com/datasheet/MCP2515T-I%252FST/197346.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: adding SPI CAN capability to MCUs that do not include an integrated CAN controller
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category can-controller, interfaces spi, can, package TSSOP-20, and EasyEDA footprint UUID 91fc5991e0a74a82ab525cc9f2487f9f.
