74HC595

Identity

Manufacturer: GR(国睿)
Model / MPN: 74HC595
LCSC: C18164493
Category: shift-register
Description: 8-bit CMOS shift register, 2V~~6V, Serial-to-Serial or Parallel, 10MHz, 1 element, 8 bits, Tri-State, 74HC, -40°C~~+85°C
Source: EasyEDA/JLC verified common component seed
Project designators: Not project-specific
Project quantity per board: Not project-specific

Capabilities

spi: interface
gpio: interface

Package And Footprint

Package / footprint name: SOP-16
Pin count: 16
EasyEDA symbol UUID: 13cd782e53c949498ccc50f8cc6a2fea
EasyEDA footprint UUID: 5a38dfa2dfc54a84af1028ca812eb98d
EasyEDA device UUID: f36665f2700f47f78792db83cf3e2012
EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

Active current: Not characterized in seed; extract active current from datasheet tables.
Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
Supply rails: EasyEDA property: 2V~6V.
Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

JLC class: Extended Part
JLC note / assembly basis: EasyEDA/JLC verified common logic, level-shifting, bus-interface, and analog-switch seed
Assembly status: jlc_extended
Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

Datasheet / product URL: https://item.szlcsc.com/datasheet/74HC595/19305556.html
Product URL: https://item.szlcsc.com/datasheet/74HC595/19305556.html
Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

Good for: low-cost GPIO expansion for LED banks, digital inputs, and simple scanned controls
Avoid when: Not captured yet.
Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
Equivalent search hints: match category shift-register, interfaces spi, gpio, package SOP-16, and EasyEDA footprint UUID 5a38dfa2dfc54a84af1028ca812eb98d.
