1206W4F1003T5E

Identity

• Manufacturer: UNI-ROYAL(厚声)
• Model / MPN: 1206W4F1003T5E
• LCSC: C17900
• Category: resistor
• Description: 1206 100kΩ ±1% 250mW thick film resistor; max 200V; TCR ±100ppm/°C; -55°C~+155°C
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: 1206
• Pin count: Unknown
• EasyEDA symbol UUID: 8b6678b777d649048a6c58fc25682fd9
• EasyEDA footprint UUID: 878e4795cf9f4d318e388d05a2d27362
• EasyEDA device UUID: 385d57fcd0334d16a3385da3b4957c72
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 200V
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: EasyEDA/JLC verified resistor and capacitor value/package expansion seed
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/1206W4F1003T5E/18588.html
• Product URL: https://item.szlcsc.com/datasheet/1206W4F1003T5E/18588.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category resistor, interfaces none captured, package 1206, and EasyEDA footprint UUID 878e4795cf9f4d318e388d05a2d27362.
