TYPE-C-31-M-12

Identity

• Manufacturer: 韩国韩荣
• Model / MPN: TYPE-C-31-M-12
• LCSC: C165948
• Category: usb-c-connector
• Description: Type-C 母 卧贴 20V Connector Type:Type-C Protocol Standard:- Gender:Female Mounting Type:Surface Mount, Right Angle Number of Contacts:16P Number of Ports:1 Current Rating-Power:5A Voltage Rating:20V Connect-Disconnect Life:10,000 cycles Length:7.35mm Operating Temperature:
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SMD
• Pin count: Unknown
• EasyEDA symbol UUID: e30d694d838e433dbe5423a6e817759e
• EasyEDA footprint UUID: 45d257a27a304edd865bdb43b1945b61
• EasyEDA device UUID: 730e76758f9742ca9ca85c73f4ec0ecd
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: 20V
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified parts for the automotive accessory control module MVP
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/TYPE-C-31-M-12/177331.html
• Product URL: https://item.szlcsc.com/datasheet/TYPE-C-31-M-12/177331.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category usb-c-connector, interfaces none captured, package SMD, and EasyEDA footprint UUID 45d257a27a304edd865bdb43b1945b61.
