CP2102N-A02-GQFN28

Identity

• Manufacturer: SKYWORKS/SILICON LABS(芯科)
• Model / MPN: CP2102N-A02-GQFN28
• LCSC: C1550553
• Category: usb-uart-bridge
• Description: CP2102N-A02-GQFN28 3V3.6V Applications Function:USB to UART Protocol:- Voltage - Supply:3V3.6V Voltage - Supply:3V3.6V Operating Temperature:-40℃+85℃@(Ta) Operating Temperature:-40℃~+85℃@(Ta)
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• usb: interface
• uart: interface

Package And Footprint

• Package / footprint name: QFN-28-EP(5x5)
• Pin count: 28
• EasyEDA symbol UUID: 4d27ff833bef4e78b53abc713cdeacdf
• EasyEDA footprint UUID: be5d5fc2901b4ab6818e2b27ff738c2c
• EasyEDA device UUID: bff9ca60e56e4156b96b6fba563c0652
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 3V~3.6V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT basics seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/CP2102N-A02-GQFN28/1641359.html
• Product URL: https://item.szlcsc.com/datasheet/CP2102N-A02-GQFN28/1641359.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category usb-uart-bridge, interfaces usb, uart, package QFN-28-EP(5x5), and EasyEDA footprint UUID be5d5fc2901b4ab6818e2b27ff738c2c.
