TPS63020DSJR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPS63020DSJR
• LCSC: C15483
• Category: buck-boost-converter
• Description: High-efficiency single-inductor buck-boost converter, adjustable, 1.8V5.5V supply, 1.2V5.5V output, 3A, 2.4MHz, -40°C~+85°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: VSON-14-EP(3x4)
• Pin count: Unknown
• EasyEDA symbol UUID: 867c7932a5554f0cb75946c5c3aed20b
• EasyEDA footprint UUID: 592ba0aab59a439fb6bc867eb7660074
• EasyEDA device UUID: 4d1082b6a7bb4be1b1967d9b39fa2616
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 1.8V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power, analog, and interface IC seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tps63020
• Product URL: https://www.ti.com/cn/lit/gpn/tps63020
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: power-tree designs when ratings and layout constraints fit
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category buck-boost-converter, interfaces none captured, package VSON-14-EP(3x4), and EasyEDA footprint UUID 592ba0aab59a439fb6bc867eb7660074.
