G5LE-1A4 DC12

Identity

• Manufacturer: OMRON(欧姆龙)
• Model / MPN: G5LE-1A4 DC12
• LCSC: C152703
• Category: relay
• Description: G5LE-1A4 DC12 Coil Voltage:12V Contact Form:1 Set Normally Open: 1A (SPST NO) Number of Pins:- Contact Rating:10A@120VAC Switching Voltage(Max):- Coil Rated Power:- Contact Material:Silver Alloy (Cd-Free) Switching Current(Max):10A Coil Type:- Coil Resistance:- Contact
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: 插件,16.5x22.5mm
• Pin count: Unknown
• EasyEDA symbol UUID: 3de4f5694d724111ac50948731b35507
• EasyEDA footprint UUID: 9806919ef4ec445ab86ecc63b46fb1e7
• EasyEDA device UUID: f99b6b324b014c11a9e7db2ec3b42f43
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common drivers, isolation, and actuation seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/G5LE-1A4%2520DC12/164043.html
• Product URL: https://item.szlcsc.com/datasheet/G5LE-1A4%2520DC12/164043.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.
