AO3401A

Identity

• Manufacturer: AOS
• Model / MPN: AO3401A
• LCSC: C15127
• Category: p-channel-mosfet
• Description: Single P-channel MOSFET, 30V, 4A, RDS(on):47mΩ@10V/85mΩ@2.5V/60mΩ@4.5V, Vgs(th):900mV, Qg:14nC@10V, Ciss:645pF
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SOT-23
• Pin count: Unknown
• EasyEDA symbol UUID: 513ec3e70dba4986a6ac046154aae83d
• EasyEDA footprint UUID: 94c69c4d1c294ea1b3563e74aa6e8ee6
• EasyEDA device UUID: f58385f66b144586baef3753ba84f65d
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Basic Part
• JLC note / assembly basis: EasyEDA/JLC verified common IoT basics seed
• Assembly status: jlc_basic
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/AO3401A/15801.html
• Product URL: https://item.szlcsc.com/datasheet/AO3401A/15801.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category p-channel-mosfet, interfaces gpio, package SOT-23, and EasyEDA footprint UUID 94c69c4d1c294ea1b3563e74aa6e8ee6.
