MCP4725A0T-E/CH

Identity

• Manufacturer: MICROCHIP(美国微芯)
• Model / MPN: MCP4725A0T-E/CH
• LCSC: C144198
• Category: dac
• Description: MCP4725A0T-E/CH 2.7V5.5V I2C Resolution(Bits):12 Number of Channels:1 Interface:I2C Voltage - Supply:2.7V5.5V Voltage - Supply:2.7V5.5V Settling Time:6us Output Type:Voltage Buffer Integral non - linearity:2LSB Integral non - linearity:2LSB Operating Temperature:-40℃+125℃ Operatin
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• i2c: interface

Package And Footprint

• Package / footprint name: SOT-23-6
• Pin count: 6
• EasyEDA symbol UUID: 29f4f6d7abf347ccac7317e83c65963e
• EasyEDA footprint UUID: 136db59d42184a44ac8441e35d752b13
• EasyEDA device UUID: 15237a9cefa9473d8347bca3746be782
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.7V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power, analog, and interface IC seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/MCP4725A0T-E%252FCH/155530.html
• Product URL: https://item.szlcsc.com/datasheet/MCP4725A0T-E%252FCH/155530.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: analog setpoints, bias generation, sensor simulation, and simple waveform or control voltage outputs
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category dac, interfaces i2c, package SOT-23-6, and EasyEDA footprint UUID 136db59d42184a44ac8441e35d752b13.
