PGB1010603MR

Identity

• Manufacturer: Littelfuse(美国力特)
• Model / MPN: PGB1010603MR
• LCSC: C142698
• Category: ethernet-esd-array
• Description: Bidirectional 1-channel ESD protector, 24V Vrwm, 150V clamp, IEC 61000-4-2 protection, 0.06pF capacitance, -65°C~+125°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: 0603
• Pin count: Unknown
• EasyEDA symbol UUID: 5be5ef8dfbca4e07aeb64174d01092b5
• EasyEDA footprint UUID: af6a264a3dc247ebbbbbfbb53844cdc2
• EasyEDA device UUID: a11e3b8f33ae437483bde219e33825b1
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified board-safety/ESD expansion seed for interfaces not yet covered (Ethernet magjack, RS-485/RS-232 bus)
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/PGB1010603MR/154029.html
• Product URL: https://item.szlcsc.com/datasheet/PGB1010603MR/154029.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category ethernet-esd-array, interfaces none captured, package 0603, and EasyEDA footprint UUID af6a264a3dc247ebbbbbfbb53844cdc2.
