TPS22918DBVR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPS22918DBVR
• LCSC: C131941
• Category: load-switch
• Description: 5.5V, 2A load switch, active high, 1V~5.5V supply, 53mΩ RDS(on), charge pump, output discharge, soft-start.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• gpio: interface

Package And Footprint

• Package / footprint name: SOT-23-6
• Pin count: 6
• EasyEDA symbol UUID: 9a38a8dced5747989bdc3364abfd325d
• EasyEDA footprint UUID: ebc5370dc87d4461ad5320a48450ab14
• EasyEDA device UUID: e30f49de94c341bea49e53f3016845f9
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Passive part; no quiescent current.
• Sleep / standby current: Passive part; no quiescent current.
• Supply rails: Application-defined.
• Notes: Ratings are seeded from EasyEDA/LCSC properties when present; verify against datasheet for final design.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectors, power, UI, and protection seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tps22918
• Product URL: https://www.ti.com/cn/lit/gpn/tps22918
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category load-switch, interfaces gpio, package SOT-23-6, and EasyEDA footprint UUID ebc5370dc87d4461ad5320a48450ab14.
