TPS2113APWR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TPS2113APWR
• LCSC: C130052
• Category: power-mux
• Description: Dual-input single-output power mux load switch, 2.8V5.5V, 1 channel, active high, 2A max continuous, 84mΩ RDS(on), -40°C+85°C.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: TSSOP-8
• Pin count: 8
• EasyEDA symbol UUID: a9ac2daaba4846b78d4f42e760315aa0
• EasyEDA footprint UUID: cd9ecd67d47049f9b5dc073abad8625e
• EasyEDA device UUID: 4168e18bab234433b44873bb599ccbb0
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: EasyEDA property: 2.8V~5.5V.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common battery management, USB-C power, and power-path seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tps2113a
• Product URL: https://www.ti.com/cn/lit/gpn/tps2113a
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category power-mux, interfaces none captured, package TSSOP-8, and EasyEDA footprint UUID cd9ecd67d47049f9b5dc073abad8625e.
