TLV3201AIDCKR

Identity

• Manufacturer: TI(德州仪器)
• Model / MPN: TLV3201AIDCKR
• LCSC: C130037
• Category: comparator
• Description: 40ns low-power push-pull output comparator, 1 channel, 1mV Vos, 1pA Ib, 40ns propagation delay, 1mV hysteresis, CMOS, rail-to-rail input.
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• Not captured yet.

Package And Footprint

• Package / footprint name: SC-70-5
• Pin count: 5
• EasyEDA symbol UUID: 11f0e0a6f483404d99047bfc6370da4b
• EasyEDA footprint UUID: 60d745df3ae34f0d99d0523f09d5b82f
• EasyEDA device UUID: 52b1d6372083468c967ad75339961f73
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common power, analog, and interface IC seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://www.ti.com/cn/lit/gpn/tlv3201
• Product URL: https://www.ti.com/cn/lit/gpn/tlv3201
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: threshold detection, wake signals, overvoltage or undervoltage flags, and fast digital alerts
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category comparator, interfaces none captured, package SC-70-5, and EasyEDA footprint UUID 60d745df3ae34f0d99d0523f09d5b82f.
