ATGM332D-5N31

Identity

• Manufacturer: 杭州中科微
• Model / MPN: ATGM332D-5N31
• LCSC: C128659
• Category: gnss-module
• Description: ATGM332D-5N31 BDS/GNSS full-constellation positioning and navigation module
• Source: EasyEDA/JLC verified common component seed
• Project designators: Not project-specific
• Project quantity per board: Not project-specific

Capabilities

• uart: interface

Package And Footprint

• Package / footprint name: SMD,16x12.2mm
• Pin count: Unknown
• EasyEDA symbol UUID: ab9f2661292e4594975a276143970526
• EasyEDA footprint UUID: e9b44f647fce4aa08011acf8790b17c6
• EasyEDA device UUID: 6c8f7a15285048b48fda6c09308478f3
• EasyEDA library UUID: 0819f05c4eef4c71ace90d822a990e87

Power And Operating Modes

• Active current: Not characterized in seed; extract active current from datasheet tables.
• Sleep / standby current: Not characterized in seed; extract sleep/standby current from datasheet tables.
• Supply rails: Not characterized in seed; capture allowed supply rail range from datasheet.
• Notes: Seed values are search hints only. Verify power modes, rail limits, startup requirements, and reference design passives from the datasheet.

Procurement Classification

• JLC class: Extended Part
• JLC note / assembly basis: EasyEDA/JLC verified common connectivity, positioning, and RF interface seed
• Assembly status: jlc_extended
• Price-break table: Not captured in seed. Store only timestamped price-break snapshots when intentionally refreshed.
• Live stock: intentionally not stored as durable selection data; refresh externally before ordering.

Datasheet And Links

• Datasheet / product URL: https://item.szlcsc.com/datasheet/ATGM332D-5N31/139944.html
• Product URL: https://item.szlcsc.com/datasheet/ATGM332D-5N31/139944.html
• Datasheet-derived notes: Not extracted yet. Use PDF extraction to fill power modes, absolute maximums, pin functions, package variants, and reference design requirements.

Selection Notes

• Good for: reuse when package, electrical ratings, footprint, and assembly class match the project constraints
• Avoid when: Not captured yet.
• Known layout constraints: Verify package land pattern, decoupling requirements, thermal pad, RF keepouts, crystal routing, and boot straps from the datasheet.
• Equivalent search hints: match category gnss-module, interfaces uart, package SMD,16x12.2mm, and EasyEDA footprint UUID e9b44f647fce4aa08011acf8790b17c6.
